Concrete Batching Plant also known as concrete mixing plant or concrete plant, the Belt Conveyor Concrete batching Plant is the plant which use belt transport aggregate from weighting machine into concrete mixer. It is high efficiency, more energy saving and more uniform mixing.
Concrete Batching Plant also known as concrete mixing plant or concrete plant, the Belt Conveyor Concrete batching Plant is the plant which use belt transport aggregate from weighting machine into concrete mixer. It is high efficiency, more energy saving and more uniform mixing.
Concrete batching plant consists of material batching, mixing and electric control system, etc, which is professional equipment for ready mix concrete production, such as plasticity/dry concrete.
Unique concrete mixing plant is widely used in small and medium construction products, road, bridge project, and concrete prefabrication factory.
With its modularization structure, it is easy to transport, install and debug more quickly.
Mixing system choose the spiral mixing system , which has high efficiency , scale board and mixing blades adopts high-rigidity and high tenacity wearable case alloy steel, to prolong the working life.
Aggregate lifting appliance adopts frequency control, thus providing smooth and reliable operation.
PC+PLC control system ensures the high reliability.
With its virtue of precise computation, it can meet the requirement of every high performance concrete.
Human-based intelligent control facilitates the operation greatly.
|
Model |
HZS25 |
HZS35 |
HZS50 |
HZS75 |
|
Capacity(m3/h) |
25 |
35 |
50 |
75 |
|
Mixing system (twin shaft concrete mixer) |
JS500 |
JS750 |
JS1000 |
JS1500 |
|
Aggregate Feeder |
Bucket (Skip Hopper) |
|||
|
Discharging volume |
500L |
750L |
1000L |
1500L |
|
Aggregate scale hopper |
800L |
1200L |
1600L |
2400L |
|
Weighing system |
Water, Cement, Additive |
|||
|
Air system |
Air compressor, etc |
|||
|
Control system |
Computer auto-control module (PLC can be optional item) |
|||
|
After-sales service |
Erection & commissioning, operator training |
|||
Started in 1980s, Zhengzhou Unique Industrial Equipment Co., Ltd (Unique Group) is already a famous manufacturer & developer of mining and concrete construction equipments like stone crushing equipment and concrete mixing equipment in China. Our products scope mainly includes stone crusher, stone crusher plant, mobile crusher plant, belt conveyor, stationary & mobile stone crushing plant, concrete mixer plant, concrete mixer, asphalt mixing plant, concrete mold etc. We not only offer clients the products with good capability & competitive price, but also provide top service & solutions.
About UniqueMore than 30 years experience in construction platform industry.
More than 210 senior engineers in the company
Exports to more than 100 countries
We have over 30 years experiences of manufacturing stone crushers, stone crusher line,concrete mixer, concrete batching plant, construction machines.
