capacity:250-350TPH
Applications:Aggregates Shaping, Mechanism sand, Bituminous Concrete, Metal Mine, Sand Making, Chemical, Road, Railway
Materials:Limestone, Granite, Gabbro, Basalt, River Stone, Coal Gangue, Quartz, Diabase,Iron Ore, Copper Ore, Zinc Ore, Manganese Ore, etc. (for Hard Stone).
250－350TPH (output 250－350 ton per hour) production line exploit the potential of C110 as the preliminary jaw crusher. In practical production, through enlarging the outlet size, the overall output and production efficiency are improved greatly, meanwhile, the service time of machine is extended and production cost is reduced.
In secondary crushing process, single cylinder cone crushers (DP430S) and HP300 multy cylinder cone crusher operate at the same time, which ensures its output. The reduction ratio can be controlled by regulating the impact-bracket. The finished products are expected to be regular cube-shaped, needle shape take up small proportion, no inner-cracks, with high compressive strength. They are quite suitable for speedway, bridge, tunnel and other construction projects.
1.By utilizing a more efficient Round Vibrating Screen during the filtration processing, the raw material is more precisely and sufficiently classified.
2.This production line can also be perfected by other supplementary equipments so as to get further processing products.
| NO. | Equipment | Model | quantity |
| Ⅰ | Vibrating feeder | GZT1148 | 1 |
| Ⅱ | Jaw crusher | C110 | 1 |
| Ⅲ | Cone crusher | DP430S single cylinder cone crusher and HP300 multy cylinder cone crusher | 2 |
| Ⅳ | Vibrating screen | 3YK2160 and 2YK2160 | 2 |
| 1 | Belt conveyor | B1000*19M | 1 |
| 2 | Belt conveyor | B1000*11M | 1 |
| 3 | Belt conveyor | B1000*22M | 1 |
| 4 | Belt conveyor | B800*21M | 1 |
| 5 | Belt conveyor | B800*23M | 1 |
| 6 | Belt conveyor | B650*15M | 5 |
Started in 1980s, Zhengzhou Unique Industrial Equipment Co., Ltd (Unique Group) is already a famous manufacturer & developer of mining and concrete construction equipments like stone crushing equipment and concrete mixing equipment in China. Our products scope mainly includes stone crusher, stone crusher plant, mobile crusher plant, belt conveyor, stationary & mobile stone crushing plant, concrete mixer plant, concrete mixer, asphalt mixing plant, concrete mold etc. We not only offer clients the products with good capability & competitive price, but also provide top service & solutions.
About UniqueMore than 30 years experience in construction platform industry.
More than 210 senior engineers in the company
Exports to more than 100 countries
We have over 30 years experiences of manufacturing stone crushers, stone crusher line,concrete mixer, concrete batching plant, construction machines.
