500-800tph stone crusher plant
500-800tph stone crusher plant
500-800tph stone crusher plant

500-800tph stone crusher plant

Capacity:500-800tph stone crusher plant

CRUSHING MATERIAL:limestone, granite, cobble, dolomite, bluestone, iron ore, construction waste, glass, cement clinker, etc

APPLIED FIELD:This crusher widely used in quarry, mining, coal.

  • 500-800tph stone crusher plant
  • 500-800tph stone crusher plant
  • 500-800tph stone crusher plant

Product Description:

500-800TPH crushing plant features for its large scope production, good performance, convenient operation, this line can achieve high reduction ratio with great output.

The third largest Jaw crusher model C125 works as primary crushing, its over sized feed opening & unique Jaw plates make it readily crush 900mm into small sizes.

All the spare parts assembled are of top quality (bearing, motor, eccentric shaft, screen mesh, etc.), this ensure the stable working status for all the equipments.

Secondary crushing process is performed by two sets of cone crusher model CH440s and HP500 which is superior in its larger feed opening and rotor, the final product sizes can be controlled through regulating impact-bracket.

Tertiary crusher such as VSI or washing machine may work as additional mining equipments to diversify the final products, meanwhile, tailor-made dust catcher or dust cover maybe the last step to perfect this line on the basis of environmental protection.
The final products are of regular cube shape, high compressive strength, needle shape take up small proportion, no inner-cracks. They are quite suitable for speedway, bridge, tunnel and other construction projects.

27500T

Features:

1. Low energy consumption

2. Easy maintenance

3. All equipments made of high quality raw material

4. Customized equipment con

Parameters:

No. Item Model Quantity (set)
1.  Big Hopper Matched 1
2.  Vibrating feeder ZSW6013 1
3.  Jaw crusher C125 1
4.  Belt conveyor B1400x20m 1
5.  Belt conveyor B650x21m 1
6.  Belt conveyor B650x16m 1
7.  Vibrating screen F1YK1860-2P 1
8.  Belt conveyor B500x15m 1
9.  Vibrating Feeder GZG140-6 2
10.  Belt conveyor B1400x31m 1
11.  Cone crusher CH440S 1
12.  Belt conveyor B1400x40m 2
13.  Belt conveyor B1000x46m 2
14.  Vibrating screen F5YK3080-3P 2
15.  Belt conveyor B1000x22m 1
16.  Belt conveyor B1000x12m 1
17.  Belt conveyor B1000x15m 1
18.  Belt conveyor B1200x49m 1
19.  Cone crusher HP500 1
20.  Belt conveyor B1200x23m 1
21.  Sand making machine VSI1263 1
22.  Belt conveyor B1200x40m 1
23.  Vibrating screen F5YK3080-4P 1
24. Belt conveyor B650x25m 4
